Pepwave - MAX Transit MINI
The Transit Mini supports both band 71 and FirstNet, providing additional coverage as the situation demands. Band 71 operates at a 600MHz frequency that travels twice as far and works four times better in buildings than conventional LTE bands. This means Band 71 provides better coverage in remote areas as well as indoors. FirstNet (band 14) provides first responders with a specialized LTE network with more priority and network capacity.
CAT 4 device approved for these US carrier networks: T-Mobile, Verizon and AT&T.
Note for T-Mobile Users: This router has support for the new Band 71 which is the 600 MHz LTE band that are best for rural areas due to the long range support.
Designed for Mobility
The MAX Transit Mini has specialized features for vehicular deployments. Ignition sensing, which detects the ignition status of the vehicle, enables the device to turn on and off as the vehicle starts up and shuts down. It is also equipped with GPS, enabling you to track its movements. With InControl’s fleet management, you can review the route history of all your vehicles from any web browser.
USA Product Overview:
4G LTE BANDS: B2, B4, B5, B12, B13, B14, B66, B71
3G Bands: HSPA+: B2, B5
|Software||Pepwave MAX Firmware|
|WAN||Support for PPPoE, Static IP, DHCP
WAN Link Health Check
Bandwidth Allowance Monitor
Support for Dynamic DNS services
|LAN||DHCP Server for LAN Clients
Extended DHCP Option
DNS Proxy for LAN Clients
VLAN on LAN Support
|Complete VPN Solution||PepVPN
SpeedFusion Hot Failover^
256-bit AES Encryption
Pre-shared Key Authentication
IPsec VPN (Network-to-Network) *
|Networking||NAT and IP Forwarding
Many to One, One to One NAT
SIP ALG, H.323 ALG
|Advanced QoS||Individual Bandwidth Limit
-SIP, HTTPS, VPN QoS
-Custom Application QoS
|Global Positioning System||Integrated GPS
Device Location Map
Location Tracking Data with InControl 2
Fleet Management with InControl 2
|Captive Portal Support||Support for Wired and Wireless LAN clients
Support RADIUS Authentication
Time and Usage Quotas on Open Access Mode
Built-in Customizable Splash Page
|Device Management||Web Administrative Interface
Command Line Interface
InControl Cloud Management
Active Client and Session Lists
Bandwidth Usage Statistics
SNMP v1, v2c and v3
^ Requires PrimeCare Subscription, complimentary for the first year.
All specifications are subject to change without notice.
NOTE: All LTE devices require a compatible wireless plan with Pulse Cellular for purchase or can be purchased to add to an existing Pulse Cellular wireless plan account.
